Furuno NX-300 Navtex Receiver (with antenna)
- Furuno NX-300
- £630.00
DISCONTINUED
This popular Navtex has been discontinued but we are still able to source from time to time.
Furuno Navtex Receiver NX-300
Economical - Paperless Navtex receiver
The NX-300 receives NAVTEX messages and verifies the ID of received messages. It features two narrowband receivers, one tuned to the 518 kHz international Navtex frequency and the other to the 490 kHz domestic or local country frequency.
Features
- Reliable, uninterrupted reception of Navtex messages
- Designed for small boats and fishing vessels
- No consumables or paper required
- Ultra clear 4.5" backlit silver bright LCD
- Compact, stylish display and antenna unit
- 28,000-character memory capacity for message storage
- Memory backup with a long life lithium battery
- Low power consumption
- NAV Data Display mode
- Multi-language menu
- Specifications
GENERAL
| Receiving Frequency | 518 and 490 kHz selectable |
|---|---|
| Mode of Reception | F1B |
| Display Mode | Message Selection mode, Nav Data mode |
| MESSAGE STORAGE | 28,000 characters |
Screenshots
MESSAGE DISPLAY
MESSEAGE SELECT
NAV DATA
Equipment List
Standard
- NAVTEX RECEIVER NX-300
- H-FIELD ANTENNA UNIT NX-3H WITH 10M CABLE
- STANDARD INSTALLATION MATERIALS
- STANDARD SPARE PARTS
Option
- MAST MOUNTING KIT
- L-ANGLE MOUNTING BASE
- RIGHT ANGLE MOUNTING BASE
- HANDRAIL MOUNTING BASE
- ANTENNA UNIT (H-FIELD TYPE)NX-3H-D
- FLUSH MOUNT KIT (S-TYPE)
- FLUSH MOUNT KIT (F-TYPE)
Interconnection Diagram
