This is the replacement for the popular GP-32 GPS Navigator. Note that the GP-39 does now show Decca conversions on screen. If yours does not have the Decca option it may need a firmware update. The package includes an antenna, although you can use an existing antenna if replacing an old GP-30/31/32.

The latest GP-39 software now gives the option to put the head unit into SCX-21 mode, to act as a head unit for the new SCX-21 satellite compass.

Highly accurate position fixing GPS navigator with clear colour LCD

The FURUNO GPS navigator GP-39 provides accurate and reliable position fixing, thanks to a 12-channel GPS receiver combined with integrated SBAS (WAAS/EGNOS/MSAS) technology.
The GP-39 has various display modes (Plotter, Highway, Steering, NAV data, Satellite monitor and 2 user customizable modes) on the 4.2" color LCD. Up to 3,000 points of ship track, 10,000 waypoints and 100 routes (each with up to 30 waypoints) can be stored. The waypoint and route data can be exported/imported via a USB flash drive or signal converter.
The GP-39 can be networked with a fish finder, sonar, radar or other navigation equipment for feeding highly accurate navigation data.

Features

Newly designed GPS core delivers enhanced position fixing accuracy
4.2" high-resolution colour LCD
Storage for 3,000 track points, 10,000 waypoints and 100 routes
SBAS capable for better positioning calculations
Share and display position information on networked equipment such as a fish finder, sonar, radar, etc.

The GP-39 delivers the position information to an interfaced fish finder or sonar. Also, the GP-39 receives the TLL (Target Latitude/Longitude) sentence from networked fish finders or sonars and can display the received information. This allows you to mark fish school locations easily.

7 display modes available, including 2 user-customisable modes
Waypoint and route data can be exported/imported via a USB flash drive or signal converter

Waypoint, route data and setting information can be exported/imported via a USB flash drive between GP-39 units. The waypoint and route data in GP-32 can be transferred to GP-39 by means of signal converter. You can backup information, or share useful information between vessels.

Multi-language ready : English, French, Spanish, Chinese, Vietnamese, Malay, Indonesian and Thai
Easy to mount on/off the bracket

The improved hanger allows the display unit to be mounted or un-mounted easily. The display unit can be carried in the bag (standard supply).

Specifications

Display Unit

Screen Type	4.2" Colour LCD
Screen Resolution	480 (V) x 272 (H) pixels
GPS Antenna	External
Display Modes	Plotter, Highway, Steering, NAV Data, Satellite monitor, User Display (Digital, Speedometer, COG)
Language	English, French, Spanish, Chinese, Vietnamese, Malay, Indonesian, Thai

GPS / SBAS (WAAS/EGNOS/MSAS)

Receiving Type	GPS: 12 channels parallel, 12 satellites tracking, C/A code, all-in-view SBAS: 2 channels
Receiving Frequency	L1 (1575.42 MHz ± 1.023 MHz)
Accuracy	GPS: 10 m (95% of the time, HDOP≤4) WAAS: 3 m (95% of the time, HDOP≤4) MSAS: 7 m (95% of the time, HDOP≤4)
